Siemens Cerberus PYROTRONICS MXL

4 - 132
ZC2-8B Connections and Ratings
SPEAKER ZONE DECIBEL LOSS
for 25.2V RMS, 35W load
Length
Gauge
14 AWG 16 AWG 18 AWG
(feet) (loss in decibels)
200 0.2 0.3 0.6
400 0.5 0.7 1.1
600 0.7 1.1 1.6
800 0.9 1.5 2.2
1000 1.2 1.8 2.7
SPEAKER ZONE DECIBEL LOSS
for 70.7V RMS, 25W load
Length
Gauge
16 AWG 18 AWG
(feet) (loss in decibels)
200 0.04 0.06
400 0.07 0.11
600 0.11 0.17
800 0.14 0.22
1000 0.18 0.27
