I/O configuration variants
4.7 Connecting redundant I/O to the PROFIBUS DP interface
CPU 410-5H Process Automation/CPU 410 SMART
70 System Manual, 10/2013, A5E32631667-AA
Use with non-redundant encoder
• Equipotential bonding of the encoder circuit should always be at one point only (preferably encoder negative).
• Operate the two redundant modules on a common load power supply.
•
When selecting encoders, compare their properties with the specified input characteristics. Remember that this function
must always be available, regardless of whether you are using one or two inputs. Example of valid values for NAMUR
encoders: for "0" current > 0.7 mA; for "1" current > 4.2 mA.
DI 24xDC 24 V 6ES7326–1BK01–0AB0
F-module in fail-safe and standard mode
F-module in standard mode
Redundant DO dual-channel
A definite evaluation of the diagnostics information "P short-circuit" and "wire break" is not possible. Deselect these
individually in your configuration.
You cannot use the module in redundant operation for applications in hazardous areas.
You cannot use the module in redundant operation for applications in hazardous areas.
DO 16xDC 24 V/0.5 A 6ES7322-8BH01-0AB0
• The equipotential bonding of the load circuit should always take place from one point only (preferably load minus).
• Diagnostics of the channels is not possible.
• The equipotential bonding of the load circuit should always take place from one point only (preferably load minus).
F-module in fail-safe mode
Redundant AI dual-channel
F-module in fail-safe mode
