Siemens CPU 410-5H Process Automation User Manual

CPU 410-5H Process Automation/CPU 410 SMART
System Manual, 10/2013, A5E32631667-AA
203
Properties and technical specifications of CPU 410
SMART
15
15.1
CPU 410 SMART
CPU 410-5H and CPU 410 SMART
Note
Except for the special features described in this section, the CPU 410 SMART behaves like
a CPU 410
-5H. Taking this section into consideration, the statements made in this manual
about the CPU 410
-5H also apply to the CPU 410 SMART.
Hardware Upgrade Package
You need the associated Hardware Upgrade Package PCS 7 HUP 247 for configuration of
the CPU 410 SMART with PCS7. It is available under ID 82142878 at this address: AS 410
modular systems (http://support.automation.siemens.com/WW/view/en/77430465/130000)
You can only operate the CPU 410 SMART with the PCS 7 SYSTEM EXPANSION CARD
PO 800. Operation with a different SEC is not possible.
DP master interface
You cannot use external DP master interfaces with the CPU 410 SMART. Only the
integrated DP interface is available.
The CPU 410 SMART supports 48 DP slaves. The number of slots is limited to 816.
The DP interface of the CPU 410 SMART supports 1536 byte inputs and 1536 byte outputs.
The address range is from 0 to 16 KB.
PN/IO controller
You cannot use an external IO controller with the CPU 410 SMART. Only the integrated
PN/IO interface is available.
The CPU 410 SMART supports 48 PNIO devices. The number of slots is limited to 1536.
The PN/IO interface of the CPU 410 SMART supports 1536 byte inputs and 1536 byte
outputs.
The address range is from 0 to 16 KB.
Fail-safe operation
You cannot use the CPU 410 SMART as fail-safe CPU. Fail-safe operation is not supported.
