System modifications during redundant operation
10.5 Editing CPU parameters
CPU 410-5H Process Automation/CPU 410 SMART
158 System Manual, 10/2013, A5E32631667-AA
Result
The standby CPU switches to STOP mode, the master CPU remains in RUN mode, the
fault-tolerant system works in single mode. The one-sided I/O of the standby CPU is no
longer addressed.
10.5.4
Step 3: Downloading a new hardware configuration to the reserve CPU
Starting situation
The fault-tolerant system is operating in single mode.
Procedure
Load the compiled hardware configuration in the reserve CPU that is in STOP mode.
Note
The user program and connection configuration cannot be downloaded in single mode.
Result
The modified CPU parameters in the new hardware configuration of the standby CPU do not
yet have an effect on ongoing operation.
10.5.5
Step 4: Switching to CPU with modified configuration
Starting situation
The modified hardware configuration is downloaded to the reserve CPU.
Procedure
1. In SIMATIC Manager, select a CPU of the fault-tolerant system, then choose "PLC >
Operating Mode" from the menu.
2. In the "Operating Mode" dialog box, click the "Switch to..." button.
3. In the "Switch" dialog box, select the "with altered configuration" option and click the
"Switch" button.
4. Acknowledge the prompt for confirmation with "OK".
