122/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 12 Actuators X53 / X54 25.09.2013
No. Parameter
601
Selection of reference point
Index 0 = fuel
Index 1 = air
0 = closed (<0°)
1 = open (>90°)
602
Actuator's direction of rotation
Index 0 = fuel
Index 1 = air
0 = counterclockwise
1 = clockwise (exclusively for SQM3...)
606
Tolerance limit of position monitoring (0.1°)
Index 0 = fuel
Index 1 = air
Greatest position error where an error is securely detected
error detection band: (parameter 606 -0.6°) up to parameter 606
608
Fuel 1: Selection of reference point
0 = closed (<0°)
1 = open (>90°)
609
Fuel 1: Actuator's direction of rotation
0 = counterclockwise
1 = clockwise (exclusively for SQM3...)
610
Fuel 1: Tolerance limit of position monitoring (0.1°)
Index 0 = fuel
Index 1 = air
Greatest position error where an error is securely detected
Error detection band: (P606 -0.6°) up to P606
611
Type of reference
Index 0 = fuel
Index 1 = air
0 = standard
1 = range stop in the usable range
2 = internal range stop (SQN1…)
3 = both
612
Fuel 1: Type of reference for fuel actuator
0 = standard
1 = range stop in the usable range
2 = internal range stop (SQN1…)
3 = both
613 Type of actuator
Index 0 = fuel
Index 1 = air
0 = 5 s / 90° (1 Nm, 1,2 Nm, 3 Nm)
1 = 10 s / 90° (6 Nm)
2 = 17 s / 90° (10 Nm)
614 Fuel 1: Type of actuator
0 = 5 s / 90° (1 Nm, 1,2 Nm, 3 Nm)
1 = 10 s / 90° (6 Nm)
2 = 17 s / 90° (10 Nm)
Application note!
Single-sided load torque is recommended due to the type of gear train for the
SQM33.6 / SQM33.7 actuators. In the event of load on both sides, a backlash of 0.3°
must also be considered in addition to plant design or setting
