Building Technologies Division Basic documentation LMV36... CC1P7544en

Infrastructure & Citiies Sector 23 Operating the AZL2... unit 25.09.2013

23.2 Meaning of symbols on the display

Parameter setting mode

Info mode

Service mode

Actuator closing

Actuator opening

Fan motor controlled

Oil preheater on

Heat request from controllers

Ignition controlled

Valve controlled

Flame present

Fault status message

Unit of current display

Bild 2e/0807

Figure 94: Meaning of display

23.3 Brightness of display

Only available with backlit LCD:

The function of the backlit display is dependent on the type of basic unit.

The brightness of the display can be adjusted from 0…100% using parameter 126.

No. Parameter

126 Display brightness
