97/248

Building Technologies Division Basic documentation LMV36... CC1P7544en

Infrastructure & Citiies Sector 8 AGM60... 25.09.2013

8 AGM60...

8.1 System with AGM60... and one fuel actuator

LMV...

Bild 314e/1010

Fuel actuator

GM60...

AIR X53

FUEL X54

Air actuator

ACT1_OUT_A

ACT1_OUT_B

ACT1_IN_A

ACT1_IN_B

SQN1...

SQM3...

ACT0_OUT_A

ACT0_OUT_B

ACT0_IN_A

ACT0_IN_B

SQN1...

SQM3...

Figure 71: LMV36... with AGM60... and one fuel actuator

8.2 System with AGM60... and two fuel actuators

LMV...

Bild 315e/1010

Fuel actuator

AGM60...

AIR X53

FUEL X54

Air actuator

ACT1_OUT_A

ACT1_OUT_B

ACT1_IN_A

ACT1_IN_B

SQN1...

SQM3...

GV61.100

ACT0_OUT_A

ACT0_OUT_B

ACT0_IN_A

ACT0_IN_B

SQN1...

SQM3...

ACT0_OUT_A

ACT0_OUT_B

ACT0_IN_A

ACT0_IN_B

SQN1...

SQM3...

Figure 72: LMV36... with AGM60... and two fuel actuator
