7.2.3 No flame at the end of safety time (TSA)
If no flame is established by the end of the first safety time, the unit initiates lockout.
Error
code
Diagnostic
code
Meaning for the LMV36... system
2 1 No flame at the end of safety time 1 (TSA1)
2 No flame at the end of safety time 2 (TSA2)
7.2.4 Flame intensity
The flame’s intensity can be displayed. It is standardized from 0 to 100%.
No. Parameter
954 Intensity of flame

Note
Also refer to chapter Intensity of flame during curve settings.
7.2.5 Supervision of flame detector
Error
code
Diagnostic
code
Meaning for the LMV36... system
93 3 Short-circuit of flame detector
At the QRB… flame detector’s input, the LMV36... checks the detector for short-circuits
in operation.
