Siemens LMV36.520A1 - Fuel-Air Ratio Curves Settings

193/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 28 Parameter level 25.09.2013
28.11 Fuel-air ratio curves – settings and commissioning
P
Vhmins%
Bild 94/0707
The display shows 400: flashing on the left,
SEt appears on the right.
28.11.1 Initial commissioning
P
Vh
mi n
s%
Bild 95/0707
An unprogrammed unit or a unit whose operating
mode has been reset or changed displays OFF UPr0
or OFF UPr1.
For initial commissioning, change to the parameter level (refer to chapter Operation).
The settings can then be made on parameter level 400.
/
reset
P
Vhmins%
Bild 94/0707
Press
/
reset
to select parameter 400 for initial
commissioning and for setting fuel-air ratio control.
/
reset
P
Vhmins%
Bild 96/0707
Press
/
reset
to go to the settings for fuel-air ratio control
and parameter 201 for selecting the operating mode.
201: appears flashing.
