Siemens LMV36.520A1 - 29 Parameter List LMV36

214/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 29 Parameter list LMV36... 25.09.2013
29 Parameter list LMV36...
Par. Parameter Number of Type Edit Value range Resolution Default Password level
no. LMV36... elements Min Max setting
000 Internal parameters
041 Password heating engineer (4 characters) 1 Std_u16 Edit 0 65535 1 OEM
042 OEM password (5 characters) 1 Std_u16 Edit 0 65535 1 OEM
050 Backup / Restore via AZL2... / PC software starting (parameterizing
on 1)
Index 0 = store backup
Index 1 = start restore
Error diagnostic via negative value (refer to error code 137)
2 Std_s8 Edit -99 50 1 0; 0 SO
055 Burner ID of AZL2... backup data record 1 Std_s32 Read only 0 99999999 1 0 SO
056 ASN summary of AZL2... backup data record 8 Std_u8 Read only 0 127 1 0 SO
057 Software version when setting the AZL2... backup data record 1 Hex_16 Read only 0x100 0xFFF9 1 0 SO
100 General
102 Identification date 1 Date Read only 0 255 1 Info / Service
103 Identification number 1 Std_u16 Read only 0 65535 1 Info / Service
104 Preselected parameter set: Customer code 1 Std_u8 Read only 0 255 1 9 Info / Service
105 Preselected parameter set: Version 1 Hex_16 Read only 0 0xFFFF 1 V 01.06 Info / Service
107 Software version 1 Hex_16 Read only 0x100 0xFFF9 1 V 03.40 Info / Service
108 Software variant 1 Std_u8 Read only 0 255 1 2 Info / Service
111 ASN summary for verification with AZL2... backup data restore 8 Std_u8 Read only 0 127 1 0 SO
113 Burner identification 1 Std_s32 Edit 0 99999999 1 undefined Info / Service
Password level
write: SO
121 Manual output
Undefined = automatic mode
1 Output Edit / clear 0% 100% 0.1% undefined Info / Service
123 Minimum output positioning step
Index 0 = output building automation
Index 1 = output external load controller analog
Index 2 = reserved
3 Output Edit 0 % 100 % 0.1 % Index
0
1
2
Value
0%
1%
0%
SO
124 Loss of flame test (TÜV test) starting (parameterized on 1)
(switch off the fuel valves
 loss of flame)
1 Std_s8 Edit -6 1 1 0 SO
