Siemens LMV36.520A1 - Page 215

215/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 29 Parameter list LMV36... 25.09.2013
Par. Parameter Number of Type Edit Value range Resolution Default Password level
no. LMV36... elements Min Max setting
Error diagnostic via negative value (refer to error code 150)
125 Mains frequency
0 = 50 Hz
1 = 60 Hz
1 Selection Edit 0 1 1 0 SO
126 Display brightness 1 Std_u8 Edit 0% 100% 1% 100 % SO
127 Timeout for menu operation 1 Std_u8 Edit 10 min 120 min 1 min 60 min OEM
128 Fuel meter: Pulse valency [pulses / volume unit] 1 Std_u16 Edit 0 400 0.01 0 SO
129 Fuel meter 1: Pulse valency [pulse / unit of volume] 1 Std_U16 Edit 0 400 0.01 0 SO
130 Delete display of error history
To delete the display: Set parameter to 1, then to 2
Return value 0: Job successfully completed
Return value -1: Timeout of 1_2 sequence
1 Std_s8 Edit -5 2 1 0 SO
133 Default output at TÜV test
Invalid = TÜV test at active output
2000...10000 = low-fire...high-fire or stage 1 / stage 2 / stage 3
1 Output Edit / clear 20 % 100 % 0.1 % Undefined SO
134 Fuel 1: Default output at TÜV test
Invalid = TÜV test at active output
2000...10000 = low-fire...high-fire or stage 1 / stage 2 / stage 3
1 Output Edit / clear 20 % 100 % 0.1 % Undefined SO
141 Operating mode BACS
0 = off
1 = Modbus
2 = reserved
1 Selection Edit 0 2 1 0 SO
142 Setback time in the event of communication breakdown
Setting value:
0 = inactive
1…7200 s
1 Std_u16 Edit 0 s 7200 s 1 s 120 s SO (BA)
143 reserved 1 Std_u8 Edit 1 8 1 1 Info / Service
144 reserved 1 Std_u16 Edit 10 s 60 s 1 s 30 s SO
145 Device address for Modbus of basic unit
Setting value:
1…247
1 Std_u8 Edit 1 247 1 1 SO
146 Setting of Baud rate for Modbus communication 1 Selection Edit 0 1 1 1 SO
