23.4 Special functions
23.4.1 Manual lockout
/
reset
plus other button
P
Vh
mi n
s%
Bild 3/0707
Press
/
reset
simultaneously with any other
button.
The basic unit switches instantly to the lockout
position, irrespective of the operating position.
The display shows the fault status message,
except when in parameter setting mode.
23.4.2 Manual control (manual request for output)
P
Vh
mi n
s%
Bild 4/0707
Burner is in operation.
The display shows oP: on the left, the
percentage of the current output on the right.
Example: oP: 20.0
F
1 s
P
Vh
mi n
s%
Bild 5/0707
Press
F
for 1 s.
The display shows LoAd:, the current output
flashes.
F
and
or
P
Vh
mi n
s%
Bild 6/0707
Press
or to adjust the required
manual output.
Example: oP: 23.0
P
Vh
mi n
s%
Bild 7/0707
Release
F
.
The current manual output flashes, indicating
that manual control is activated.
ESC
P
Vh
mi n
s%
Bild 8/0707
Press
E
SC
for 3 seconds to return to
automatic mode.
The output no longer flashes.
The display shows oP: on the left, the
percentage value on the right.
Example: oP: 23.0
