Siemens LMV36.520A1 - Light Oil Direct Ignition Lo, Lo Mod, Lo 2-Stage, Lo 3-Stage

To Next Page

To Previous Page

92/248

Building Technologies Division Basic documentation LMV36... CC1P7544en

Infrastructure & Citiies Sector 7 Basic unit 25.09.2013

7.7.4 Light oil direct ignition «Lo», «Lo mod», «Lo 2-stage», «Lo

3-stage»

Fuel

Air

0°

R (ON)

0°

5 s5 s 30 s

POC *)

Function / Inputs

Function / Outputs

RAST plug

Pin number

RAST plug

Pin number

X3-04 Pin 1/2

X5-03 Pin 1/4

X10-05

Pin 2 / Pin 3/4

X10-06 Pin 1/2

X3-02 Pin 1/2

X5-01 Pin 2/3

X5-02 Pin 2/3

X3-05 Pin 1

X4-02 Pin 2/3

X6-03 Pin 2/3

X8-02 Pin 1/3

X7-01 Pin 2/3

X7-02 Pin 2/3

X3-05 Pin 2

X54

X53

X74

Figure 69: Program for light oil direct ignition (Lo), (Lo mod), (Lo 2-stage), (Lo 3-stage)
