Siemens LMV36.520A1 - Page 124

124/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 12 Actuators X53 / X54 25.09.2013
Example of actuator with counterclockwise rotation:
When referencing in the CLOSED position, the actuator first travels a certain distance
into the working range (toward the OPEN position). Then, it travels to a position
representing maximum -7.7°, thereby crossing the reference mark for the fist time. Then,
the actuator moves in the other direction again and detects the inner ramp of the
reference mark. This is the reference point used by all positions. If the reference point is
parameterized in the OPEN position, referencing takes place in a mirror-symmetrical
manner. In that case, the actuator first travels into the working range (toward the OPEN
position). Then, it crosses the reference mark and travels to a position representing
maximum 110.6°, then back to the inner ramp of the reference mark.
90
°
(u
s
able
ra
n
g
e
)
Close (0° 0.6°)
+
Reference range "Close"
Range stop "Close"
Reference range "Open"
M
o
d
u
l
a
t
i
o
n
r
a
n
g
e
Range stop "Open"
1
8
.
5
°
2
0
.
6
°
5
.
6
°
7.7°
+
1
1
0
.
6
°
(
w
o
r
k
i
n
g
r
a
n
g
e
f
o
r
r
e
fe
r
e
n
c
i
n
g
“
O
p
e
n
”
)
Figure 79: Angle definitions with SQM33…
Error
code
Diagnostic
code
Meaning for the LMV36... system
85 0 Referencing error of fuel actuator
1 Referencing error of air actuator
Bit 7
Valency ≥128
Referencing error due to parameter change
