Siemens LMV36.520A1 - Page 189

189/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 28 Parameter level 25.09.2013
Adopt the value!

/
reset
ESC

Discard the change!
P
Vh
mi n
s%
Bild 81/0707
Press
/
reset
to return to editing mode.
The value set will be adopted.
P
Vh
mi n
s%
Bild 78/0707
Press
ESC
to return to the index.
Display: Parameter 501. does not flash, index
01: flashes, value 0.0 has not changed and
does not flash.
Note
To detect potential display errors, the value is
displayed 1 place shifted to the right.
Display: Value 1.0
ESC
P
Vh
mi n
s%
Bild 82/0707
Press
E
SC
to return to the index.
PArAmeter 501: does not flash, index 01:
flashes, value 1.0 does not.
ESC
P
Vh
min
s%
Bild 83/0707
Press
E
SC
to return to the parameter
level.
Display: Parameter 501. flashes, index 00:
and value 0.0 do not.
ESC
P
Vhmins%
Bild 75/0707
Press
E
SC
to return to the parameter
level.
PArAmeter 500: for fuel-air ratio control.
