Siemens LMV36.520A1 - Page 210

210/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 28 Parameter level 25.09.2013
P
Vh
mi n
s%
Bild 117/0707
Phase Traveling to ignition position
P
Vh
mi n
s%
Bild 119/0707
Phase Preignition
P
Vh
mi n
s%
Bild 120/0707
Phase 1st safety time (ignition transformer ON)
P
Vh
mi n
s%
Bild 122/0707
Phase Interval 1
A
and
or
as well as
F
and
A
and
or
P
Vh
mi n
s%
Bild 149/0707
Ignition position P0 can be set only when
symbol ▲ or ▼ is no longer highlighted.
Keep
A
depressed and, for VSD
F
and
A
.
Press
or to adjust the value.
When symbol ▲ or ▼ is no longer
highlighted, the next curvepoint P1 can be
selected with
.
