Siemens LMV36.520A1 - Light Oil Direct Ignition

81/248
Building Technologies Division Basic documentation LMV36... CC1P7544en
Infrastructure & Citiies Sector 7 Basic unit 25.09.2013
1-stage burner
LO
Program
P
min
V1
Figure 49: Light oil direct ignition, multistage
2-stage burner
LO
Program
P
min
V1
V2
Figure 50: Light oil direct ignition, 2-stage
3-stage burner
LO
Program
P
min
V1
V2
V3
Figure 51: Light oil direct ignition, 3-stage
Light oil direct ignition,
multistage
(Operating mode 5, 17)
(Operating mode 5, 17)
(Operating mode 6, 18)
