Issue 10/06 5 MICROMASTER 440 specifications
MICROMASTER 440 Operating Instructions
6SE6400-5AW00-0BP0
265
Table 5-3 Current reduction depending on pulse frequency
Output current in A with a switching frequency of; Mains voltage Power (CT)
[kW]
4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 14 kHz 16 kHz
0.12 to 5.5 Factory setting 16 kHz – no derating necessary
7.5 28.0 26.6 25.2 22.4 19.6 16.8 14.0
11 42.0 37.8 33.6 29.4 25.2 21.0 16.8
15 54.0 48.6 43.2 37.8 32.4 27.0 21.6
18.5 68.0 64.6 61.2 54.4 47.6 40.8 34.0
22 80.0 72.0 64.0 56.0 48.0 40.0 32.0
30 104.0 91.0 78.0 70.2 62.4 57.2 52.0
37 130.0 113.8 97.5 87.8 78.0 71.5 65.0
1/3 AC 200 V
45 154.0 134.8 115.5 104.0 92.4 84.7 77.0
0.37 1.3 1.3 1.3 1.3 1.3 1.2 1.0
0.55 1.7 1.7 1.7 1.6 1.5 1.4 1.2
0.75 2.2 2.2 2.2 2.0 1.8 1.5 1.3
1.1 3.1 2.9 2.8 2.5 2.2 1.9 1.6
1.5 4.1 3.7 3.3 2.9 2.5 2.1 1.6
2.2 5.9 5.6 5.3 4.7 4.1 3.5 3.0
3.0 7.7 6.9 6.2 5.4 4.6 3.9 3.1
4.0 10.2 9.2 8.2 7.1 6.1 5.1 4.1
5.5 13.2 11.9 10.6 9.2 7.9 6.6 5.3
7.5 19.0 18.1 17.1 15.2 13.3 11.4 9.5
11.0 26.0 23.4 20.8 18.2 15.6 13.0 10.4
15.0 32.0 30.4 28.8 25.6 22.4 19.2 16.0
18.5 38.0 34.2 30.4 26.6 22.8 19.0 15.2
22 45.0 40.5 36.0 31.5 27.0 22.5 18.0
30 62.0 58.9 55.8 49.6 43.4 37.2 31.0
37 75.0 67.5 60.0 52.5 45.0 37.5 30.0
45 90.0 76.5 63.0 51.8 40.5 33.8 27.0
55 110.0 93.5 77.0 63.3 49.5 41.3 33.0
75 145.0 112.4 79.8 68.9 58.0 50.8 43.5
90 178.0 – – – – – –
110 205.0 – – – – – –
132 250.0 – – – – – –
160 302.0 – – – – – –
3 AC 400 V
200 370.0 – – – – – –
0.75 1.4 1.2 1.0 0.8 0.7 0.6 0.6
1.5 2.7 2.2 1.6 1.4 1.1 0.9 0.8
2.2 3.9 2.9 2.0 1.6 1.2 1.0 0.8
4.0 6.1 4.6 3.1 2.4 1.8 1.5 1.2
5.5 9.0 6.8 4.5 3.6 2.7 2.3 1.8
7.5 11.0 8.8 6.6 5.5 4.4 3.9 3.3
11.0 17.0 12.8 8.5 6.8 5.1 4.3 3.4
15.0 22.0 17.6 13.2 11.0 8.8 7.7 6.6
18.5 27.0 20.3 13.5 10.8 8.1 6.8 5.4
22 32.0 24.0 16.0 12.8 9.6 8.0 6.4
30 41.0 32.8 24.6 20.5 16.4 14.4 12.3
37 52.0 39.0 26.0 20.8 15.6 13.0 10.4
45 62.0 52.7 43.4 40.3 37.2 32.6 27.9
55 77.0 67.4 57.8 52.0 46.2 42.4 38.5
3 AC 500 V
75 99.0 84.2 69.3 64.4 59.4 52.0 44.6
