Siemens Simantic ET200SP User Manual

Application planning
3.3 Hardware configuration
Distributed I/O system
System Manual, 12/2016, A5E03576849-AG
41
3.3
Hardware configuration
Maximum mechanical configuration
As soon as
one
of the following rules applies, the maximum configuration of the ET 200SP
has been reached:
Table 3- 3 Maximum mechanical configuration
Properties
Rule
Number of modules Maximum of 12/30/32/64 I/O modules (depending on the CPU
used/the interface module used; see CPU
(http://support.automation.siemens.com/WW/view/en/9046643
9/133300) and interface module
(http://support.automation.siemens.com/WW/view/en/5568331
6/133300) manuals)
For every 6 F-modules F-RQ 1x24VDC/24..230VAC/5A
(6ES7136-6RA00-0BF0), the maximum configuration is re-
duced by 1 module.
Number of motor starters
Maximum of 31 motor starters
Backplane bus length of the
ET 200SP
maximum 1 m mounting width (without CPU/interface module,
including server module)
Electrical maximum configuration for I/O modules
The number of operable I/O modules of a potential group is limited by the following factors:
● Power consumption of the I/O modules
● Power consumption of the components supplied via these I/O modules
The maximum current carrying capacity of the terminals on the BaseUnit L+/M is 10 A.
Current carrying capacity refers to the current load via the power bus and the infeed bus of
the ET 200SP station. Consider the current carrying capacity when using a motor starter.
Maximum electrical configuration for motor starter power bus (24 V DC)
To determine the current requirement of an individual motor starter via the power bus, take
account of the following parameters:
● Current consumption via DC infeed in the ON state
● Current consumption via DC infeed when switching on (40 ms peak load)
● Increased power consumption through fan operation
● Current requirement via encoder supply of the connected DI module
The maximum current carrying capacity of the 24 V potential group is 7 A across the entire
permissible temperature range.

Siemens Simantic ET200SP Specifications

General

System Type	Modular I/O System
Mounting	DIN Rail
Power Supply	24 V DC
Category	I/O Systems
Protection Class	IP20
Modularity	Yes
Communication Protocols	PROFINET, PROFIBUS
Digital Inputs	Available (varies by module)
Digital Outputs	Available (varies by module)
Analog Inputs	Available (varies by module)
Analog Outputs	Available (varies by module)
Number of Modules per Station	Up to 64
Module Width	15 mm, 20 mm, 22.5 mm (depending on module type)
