Interrupts/diagnostic alarms
14.4 Diagnostics response
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
120 Manual, 07/2018, A5E42674880-AA
The following figure is a schematic diagram of the principle of operation:
Diagnostics "power quality"
Status "Power quality voltage dip"
Bit "Reset status "power quality""
Min. voltage dip (half-wave) and duration can be read
Figure 14-5 Example of principle of operation
