Parameter data records
A.2 Structure of the parameter data record 128 for the entire module
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
140 Manual, 07/2018, A5E42674880-AA
Structure of the parameter data record 128 for the entire module
Structure of data record 128
Figure A-1 Parameter data record 128
The figure below shows the structure of the header information.
Figure A-2 Header information
