Measured value data records
E.15 Measured value data record for harmonics current (DS 163)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
265
E.15
Measured value data record for harmonics current (DS 163)
Measured variables of the module
The measured value identification (measured value ID) is an index which references the
overview table of the measured variables in appendix B (Measured variables (Page 163)).
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
0
Version
BYTE
-
-
-
1 Reserved BYTE - - -
2...5
THD+N current L1
REAL
1%
0% to 100%
62121
6...9
Current L1
REAL
A
0.0 ... 100000.0
7
10...13
Harmonics 1: Current L1
REAL
A
0.0 ... 100000.0
63001
14...17
Harmonics 2: Current L1
REAL
A
0.0 ... 100000.0
63003
18...21
Harmonics 3: Current L1
REAL
A
0.0 ... 100000.0
63005
22...25
Harmonics 4: Current L1
REAL
A
0.0 ... 100000.0
63007
26...29
Harmonics 5: Current L1
REAL
A
0.0 ... 100000.0
63009
30...33
Harmonics 6: Current L1
REAL
A
0.0 ... 100000.0
63011
34...37
Harmonics 7: Current L1
REAL
A
0.0 ... 100000.0
63013
38...41
Harmonics 8: Current L1
REAL
A
0.0 ... 100000.0
63015
42...45
Harmonics 9: Current L1
REAL
A
0.0 ... 100000.0
63017
46...49
Harmonics 10: Current L1
REAL
A
0.0 ... 100000.0
63019
50...53
Harmonics 11: Current L1
REAL
A
0.0 ... 100000.0
63021
54...57
Harmonics 12: Current L1
REAL
A
0.0 ... 100000.0
63023
58...61
Harmonics 13: Current L1
REAL
A
0.0 ... 100000.0
63025
62...65
Harmonics 14: Current L1
REAL
A
0.0 ... 100000.0
63027
66...69
Harmonics 15: Current L1
REAL
A
0.0 ... 100000.0
63029
70...73
Harmonics 16: Current L1
REAL
A
0.0 ... 100000.0
63031
74...77 Harmonics 17: Current L1 REAL A 0.0 ... 100000.0 63033
78...81
Harmonics 18: Current L1
REAL
A
0.0 ... 100000.0
63035
82...85
Harmonics 19: Current L1
REAL
A
0.0 ... 100000.0
63037
86...89
Harmonics 20: Current L1
REAL
A
0.0 ... 100000.0
63039
90...93
Harmonics 21: Current L1
REAL
A
0.0 ... 100000.0
63041
94...97
Harmonics 22: Current L1
REAL
A
0.0 ... 100000.0
63043
98...101
Harmonics 23: Current L1
REAL
A
0.0 ... 100000.0
63045
102...105
Harmonics 24: Current L1
REAL
A
0.0 ... 100000.0
63047
106...109
Harmonics 25: Current L1
REAL
A
0.0 ... 100000.0
63049
110...113
Harmonics 26: Current L1
REAL
A
0.0 ... 100000.0
63051
114...117
Harmonics 27: Current L1
REAL
A
0.0 ... 100000.0
63053
118...121
Harmonics 28: Current L1
REAL
A
0.0 ... 100000.0
63055
122...125
Harmonics 29: Current L1
REAL
A
0.0 ... 100000.0
63057
