Siemens SIMATIC ET 200SP User Manual

Limit monitoring
9.4 Measured variables for limit monitoring
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
82 Manual, 07/2018, A5E42674880-AA
9.4
Measured variables for limit monitoring
You can use measured variables from the section Measured variables (Page 163) for limit
value monitoring.
The value range of the parameter "Limit x" is -3.0E+09 ... +3.0E+09.
The table below shows you which measured variables are not available for limit monitoring.
Measured value ID
Measured variables
220
Total active energy inflow L1L2L3
221 Total active energy outflow L1L2L3
222
Total reactive energy inflow L1L2L3
223
Total reactive energy outflow L1L2L3
224
Total apparent energy L1L2L3
225
Total active energy L1L2L3
226
Total reactive energy L1L2L3
62110
Active energy inflow L1
62111
Active energy outflow L1
62112
Reactive energy inflow L1
62113
Reactive energy outflow L1
62114
Apparent energy L1
62115
Total active energy L1
62116
Total reactive energy L1
62136
Fundamental cos φ active factor L1
62210
Active energy inflow L2
62211
Active energy outflow L2
62212
Reactive energy inflow L2
62213
Reactive energy outflow L2
62214
Apparent energy L2
62215 Total active energy L2
62216
Total reactive energy L2
62236
Fundamental cos φ active factor L2
62310
Active energy inflow L3
62311
Active energy outflow L3
62312
Reactive energy inflow L3
62313
Reactive energy outflow L3
62314
Apparent energy L3
62315
Total active energy L3
62316
Total reactive energy L3
62336
Fundamental cos φ active factor L3
65496
Power quality analysis qualifier
65497
Current module time
65500
Qualifier L1
65501
Qualifier L2
