Siemens SIMATIC ET 200SP User Manual

Measured value data records
E.16 Information data record on available measured values (DS 170)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
268 Manual, 07/2018, A5E42674880-AA
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
446...449
Harmonics 26: Current L3
REAL
A
0.0 ... 100000.0
63851
450...453 Harmonics 27: Current L3 REAL A 0.0 ... 100000.0 63853
454...457
Harmonics 28: Current L3
REAL
A
0.0 ... 100000.0
63855
458...461 Harmonics 29: Current L3 REAL A 0.0 ... 100000.0 63857
462...465
Harmonics 30: Current L3
REAL
A
0.0 ... 100000.0
63859
466...469
Harmonics 31: Current L3
REAL
A
0.0 ... 100000.0
63861
470...473
Harmonics 32: Current L3
REAL
A
0.0 ... 100000.0
63863
474...477
Harmonics 33: Current L3
REAL
A
0.0 ... 100000.0
63865
478...481
Harmonics 34: Current L3
REAL
A
0.0 ... 100000.0
63867
482...485
Harmonics 35: Current L3
REAL
A
0.0 ... 100000.0
63869
486...489
Harmonics 36: Current L3
REAL
A
0.0 ... 100000.0
63871
490...493
Harmonics 37: Current L3
REAL
A
0.0 ... 100000.0
63873
494...497
Harmonics 38: Current L3
REAL
A
0.0 ... 100000.0
63875
498...501
Harmonics 39: Current L3
REAL
A
0.0 ... 100000.0
63877
502...505
Harmonics 40: Current L3
REAL
A
0.0 ... 100000.0
63879
506...517 Current module time PNI-
OTime
sec - 65497
E.16
Information data record on available measured values (DS 170)
Measured variables of the module
Byte
Name
Data type
0
Version
BYTE
1
Reserved
BYTE
2...3
Number of IDs
UINT16
4...5
ID measured value 1
UINT16
5...6 ID measured value 2 UINT16
...
...
...
1149...1150
ID measured value 580
UINT16
