Siemens SIMATIC ET 200SP User Manual

Measured value data records
E.15 Measured value data record for harmonics current (DS 163)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
267
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
286...289
Harmonics 28: Current L2
REAL
A
0.0 ... 100000.0
63455
290...293 Harmonics 29: Current L2 REAL A 0.0 ... 100000.0 63457
294...297
Harmonics 30: Current L2
REAL
A
0.0 ... 100000.0
63459
298...301 Harmonics 31: Current L2 REAL A 0.0 ... 100000.0 63461
302...305
Harmonics 32: Current L2
REAL
A
0.0 ... 100000.0
63463
306...309
Harmonics 33: Current L2
REAL
A
0.0 ... 100000.0
63465
310...313
Harmonics 34: Current L2
REAL
A
0.0 ... 100000.0
63467
314...317
Harmonics 35: Current L2
REAL
A
0.0 ... 100000.0
63469
318...321
Harmonics 36: Current L2
REAL
A
0.0 ... 100000.0
63471
322...325
Harmonics 37: Current L2
REAL
A
0.0 ... 100000.0
63473
326...329
Harmonics 38: Current L2
REAL
A
0.0 ... 100000.0
63475
330...333
Harmonics 39: Current L2
REAL
A
0.0 ... 100000.0
63477
334...337
Harmonics 40: Current L2
REAL
A
0.0 ... 100000.0
63479
338...341
THD+N current L3
REAL
1%
0% to 100%
62321
342...345
Current L3
REAL
A
0.0 ... 100000.0
9
346...349
Harmonics 1: Current L3
REAL
A
0.0 ... 100000.0
63801
350...353
Harmonics 2: Current L3
REAL
A
0.0 ... 100000.0
63803
354...357
Harmonics 3: Current L3
REAL
A
0.0 ... 100000.0
63805
358...361
Harmonics 4: Current L3
REAL
A
0.0 ... 100000.0
63807
362...365
Harmonics 5: Current L3
REAL
A
0.0 ... 100000.0
63809
366...369 Harmonics 6: Current L3 REAL A 0.0 ... 100000.0 63811
370...373
Harmonics 7: Current L3
REAL
A
0.0 ... 100000.0
63813
374...377
Harmonics 8: Current L3
REAL
A
0.0 ... 100000.0
6381
378...381
Harmonics 9: Current L3
REAL
A
0.0 ... 100000.0
63817
382...385
Harmonics 10: Current L3
REAL
A
0.0 ... 100000.0
63819
386...389
Harmonics 11: Current L3
REAL
A
0.0 ... 100000.0
63821
390...393 Harmonics 12: Current L3 REAL A 0.0 ... 100000.0 63823
394...397
Harmonics 13: Current L3
REAL
A
0.0 ... 100000.0
63825
398...401
Harmonics 14: Current L3
REAL
A
0.0 ... 100000.0
63827
402...405
Harmonics 15: Current L3
REAL
A
0.0 ... 100000.0
63829
406...409
Harmonics 16: Current L3
REAL
A
0.0 ... 100000.0
63831
410...413
Harmonics 17: Current L3
REAL
A
0.0 ... 100000.0
63833
414...417
Harmonics 18: Current L3
REAL
A
0.0 ... 100000.0
63835
418...421
Harmonics 19: Current L3
REAL
A
0.0 ... 100000.0
63837
422...425
Harmonics 20: Current L3
REAL
A
0.0 ... 100000.0
63839
426...429
Harmonics 21: Current L3
REAL
A
0.0 ... 100000.0
63841
430...433
Harmonics 22: Current L3
REAL
A
0.0 ... 100000.0
63843
434...437
Harmonics 23: Current L3
REAL
A
0.0 ... 100000.0
63845
438...441
Harmonics 24: Current L3
REAL
A
0.0 ... 100000.0
63847
442...445
Harmonics 25: Current L3
REAL
A
0.0 ... 100000.0
63849
