Configuration / address space
4.3 Applicable modules
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
36 Manual, 07/2018, A5E42674880-AA
4.2.4
Recommendations for selecting the module version
The following table shows which module version is suitable for a given purpose.
Module version
Application
Note
2 I / 2 Q
Use of many AI Energy Meter
HF in an ET 200SP or little
address space is available
Read the measured values solely via the RDREC instruc-
tion from a measured value data record.
Quality information about the measured values is always
available.
EE@Industry measu-
rement data profile
E0 / E1 / E2 / E3
Cyclic measurement per
phase
Supplied measured values in
accordance with the
EE@Industry measured data
profile
Available measured values depend on the configured
measurement data profile.
The user data are fixed and cannot be changed dynami-
cally. Alternatively, read the measured values acyclically
from a measured value data record via the RDREC in-
struction.
No quality information
32 I / 20 Q
Cyclic measurement per
phase
Flexibility by switching prede-
fined user data variants
Quality information about the measured values is always
available.
Depending on the user data variant, you must convert
the measured values in the CPU to physical values using
the supplied scaling factor.
One cycle elapses for each user data changeover.
Measured values from the next user data variant are thus
supplied with a slight time offset.
Alternatively, read the measured values acyclically from
a measured value data record via the RDREC instruc-
tion. Consistent measured values of a measuring cycle
are supplied.
User-specific
Cyclic measurement of up to
64 measured values configu-
rable
Flexibility by switching prede-
fined user data variants
With GSD configuration
32 I / 20 Q
64 I / 20 Q
128 I / 20 Q
256 I / 20 Q
