Siemens SIMATIC ET 200SP User Manual

Configuration / address space
4.2 Selecting the module versions
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
35
Requirement
● User program has been created.
● AI Energy Meter HF is configured as one of the module versions mentioned in the figure
above.
● The start address of the module is known in the process image output.
Procedure
1. Create one constant with the data type BYTE per user data variant.
2. Enter the user data ID as a value in each case.
3. Write the constant to the start address of the module in the process image output.
Result
The user data variant is switched with the next cycle.
Note
Information about user data changeover
The parameterized user data variant is set in the following cases:
•
A "0" is written in byte 0 in the output data of a user data variant.
•
Byte 0 in the output data of a user data variant contains an invalid value:
– Coding of the user data variant not available
or
–
Available address space is not sufficient for the selected user data variant.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
