Siemens SIMATIC ET 200SP User Manual

Module versions
C.4 Module version "EE@Industry measurement data profile E0 / E1 / E2 / E3"
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
203
C.4
Module version "EE@Industry measurement data profile
E0 / E1 / E2 / E3"
User data of the module
The four versions according to EE@Industry use between 4 and 104 bytes of input user data
and 20 bytes of output user data. A dynamic switchover of the input user data is not
possible.
Structure of input user data
The structure of the input user data for the module versions according to the EE@Industry
standard is fixed and depends on the selected measurement data profile.
Table C- 6 Measurement data profile E0
Byte
Allocation
Data
type
Unit
Value range
Mea
sure
d
value
ID
0...3
Current L1
REAL
1 A
0.0 … 100000.0
7
4...7 Current L2 REAL 1 A 0.0 … 100000.0 8
8...11
Current L3
REAL
1 A
0.0 … 100000.0
9
Table C- 7 Measurement data profile E1
Byte
Allocation
Data
type
Unit
Value range
Mea
sure
d
value
ID
0...3 Total active power L1L2L3 REAL 1 W -3.0e+9 ... +3.0e+9 34
