Measured value data records
E.12 Measured value data record of user-defined data record (DS 151)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
258 Manual, 07/2018, A5E42674880-AA
88...91 Power quality analysis - Qualifier UDINT Bit
- 65496
92...103 Current module time PNI-
OTime
sec - 65497
Energy counters count periodically - counter overflow at:
Bit 0 = 1: Active energy inflow L1
Bit 1 = 1: Active energy outflow L1
Bit 2 = 1: Reactive energy inflow L1
Bit 3 = 1: Reactive energy outflow L1
Bit 4 = 1: Apparent energy L1
Bit 5 = 1: Active energy inflow L2
Bit 6 = 1: Active energy outflow L2
Bit 7 = 1: Reactive energy inflow L2
Bit 8 = 1: Reactive energy outflow L2
Bit 9 = 1: Apparent energy L2
Bit 10 = 1: Active energy inflow L3
Bit 11 = 1: Active energy outflow L3
Bit 12 = 1: Reactive energy inflow L3
Bit 13 = 1: Reactive energy outflow L3
Bit 14 = 1: Apparent energy L3
Measured value data record of user-defined data record (DS 151)
The length and structure of the data record DS 151 depends on the parameter assignment of
the data record DS 135 (Page 160).
Number of measured values
2 Measured value 1 corresponding to measured
Depending on the corresponding measured value ID
3 Measured value 2 corresponding to measured
Depending on the corresponding measured value ID
Depending on the corresponding measured value ID
... m Measured value n corresponding to measured
Depending on the corresponding measured value ID
