Configuration / address space
4.2 Selecting the module versions
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
33
Module versions with selectable user data variants
32 I / 20 Q User data selectable
through defined user
data variants
32-byte inputs /
20-byte outputs
You can change over the user data variant during opera-
tion.
Information about the structure of the 32 I / 20 Q module
version is available in appendix Module version "32 I / 20
Q" (Page 195).
Information about the user data variants at 32 I / 20 Q is
available in appendix User data variants (Page 205).
User-specific User data selectable
through user data map-
ping or through defined
user data variant
variable* /
20-byte outputs
You have to activate the check box "User data-mapping"
in STEP 7 to use the module version user-specifically.
You can change over the user data variant during opera-
tion.
Information about the structure of the user-specific module
version is available in the appendix
"User-specific" module
* 16 ... 256 bytes in steps of 16 bytes, depending on the mapped measured values
Module versions at configuration with GSD file
Module versions with fixed user data assignment
2 I / 2 Q No cyclic user data.
Access to measured
values through "Read
2-byte inputs
2-byte outputs
Information about the structure of the 2 I / 2 Q module
version is available in the appendix Module version "2 I / 2
Q" (Page 192).
E0 User data in accordance
with EE@Industry meas-
urement data profiles
12-byte inputs /
Information about the structure of the EE@Industry meas-
ured data profiles is available in the appendix Module
version "EE@Industry measurement data profile E0 / E1 /
E2 / E3" (Page 203).
E1 4-byte inputs /
E2 12-byte inputs /
20-byte outputs
E3 104-byte inputs /
