Siemens SIMATIC ET 200SP - Structure for Energy Counters (DS 143)

Measured value data records
E.3 Structure for energy counters (DS 143)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
232 Manual, 07/2018, A5E42674880-AA
E.3
Structure for energy counters (DS 143)
Energy meter data record 143 for different actions
The energy meter data record 143 includes all energy meters available on the module
phase-by-phase. The data record can be used for different actions:
● Reset the energy meters to user-specific value (e.g. "0")
● Reading the current values of the energy counters
● Reading the overflow counters
● Reading the operating hours
Energy meter data record 143
Table E- 3 Energy meter data record 143
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
0
Version
BYTE
-
1
-
1 Reserved BYTE - 0 -
2 Status / control byte 1 - L1 BYTE Bit
string
- -
3 Status / control byte 2 - L1 BYTE Bit
string
4 Status / control byte 1 - L2 BYTE Bit
string
5 Status / control byte 2 - L2 BYTE Bit
string
6 Status / control byte 1 - L3 BYTE Bit
string
7 Status / control byte 2 - L3 BYTE Bit
string
8...15
Active energy inflow (initial value) L1
LREAL
Wh
During reading:
0.0...1.8 x 10
308
During writing
For continuous counting:
0.0...3.4 x 10
12
During writing
For periodic counting:
61180
16...23
Active energy outflow (initial value) L1
LREAL
Wh
61181
24...31
Reactive energy inflow (initial value) L1
LREAL
varh
61182
32...39
Reactive energy outflow (initial value) L1
LREAL
varh
61183
40...47
Apparent energy (initial value) L1
LREAL
VAh
61184
48...55
Active energy inflow (initial value) L2
LREAL
Wh
61200
56...63 Active energy outflow (initial value) L2 LREAL Wh 61201
64...61
Reactive energy inflow (initial value) L2
LREAL
varh
61202
72...79
Reactive energy outflow (initial value) L2
LREAL
varh
61203
80...87
Apparent energy (initial value) L2
LREAL
VAh
61204
88...95
Active energy inflow (initial value) L3
LREAL
Wh
61220
