E.5 Measured value data record for maximum values with time stamp (DS 154)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
239
E.5
Measured value data record for maximum values with time stamp
(DS 154)
Measured variables of the module
The largest values ever measured or calculated from the time AI Energy Meter HF was
started are stored in this data record.
The measured values (REAL 4 bytes) are each followed by a time stamp (PN Time 12
bytes).
The measured value identification (measured value ID) is an index which references the
overview table of the measured variables in appendix B (Measured variables (Page 163)).
Byte
Measured variable
Data
type
Unit
Default
Meas-
ured
value
ID
0
Version
UINT8
-
1
-
1 Reserved UINT8 - 0 -
2...17 Max. voltage L1-N REAL +
PN Time
V 0 40
18...33 Max. voltage L2-N REAL +
PN Time
V 0 41
34...49 Max. voltage L3-N REAL +
PN Time
V 0 42
50...65 Max. voltage L1-L2 REAL +
PN Time
V 0 43
66...81 Max. voltage L2-L3 REAL +
PN Time
V 0 44
82...97 Max. voltage L3-L1 REAL +
PN Time
V 0 45
98...113 Max. current L1
1
REAL +
PN Time
A 0 46
114...129 Max. current L2
1
REAL +
PN Time
A 0 47
130...145 Max. current L3
1
REAL +
PN Time
A 0 48
146...161 Max. apparent power L1 REAL +
PN Time
VA 0 49
162...177 Max. apparent power L2 REAL +
PN Time
VA 0 50
178...193 Max. apparent power L3 REAL +
PN Time
VA 0 51
194...209 Max. active power L1 REAL +
PN Time
W -3.0 x 10
9
52
210...225 Max. active power L2 REAL +
PN Time
W -3.0 x 10
9
53
