Measured value data records
E.5 Measured value data record for maximum values with time stamp (DS 154)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
240 Manual, 07/2018, A5E42674880-AA
Byte
Measured variable
Data
type
Unit
Default
Meas-
ured
value
ID
226...241 Max. active power L3 REAL +
PN Time
W -3.0 x 10
9
54
242...257 Max. reactive power Qtot L1 REAL +
PN Time
var -3.0 x 10
9
62160
258...273 Max. reactive power Qtot L2 REAL +
PN Time
var -3.0 x 10
9
62260
274...289 Max. reactive power Qtot L3 REAL +
PN Time
var -3.0 x 10
9
62360
290...305 Max. power factor λ L1 REAL +
PN Time
- 0 58
306...321 Max. power factor λ L2 REAL +
PN Time
- 0 59
322...337 Max. power factor λ L3 REAL +
PN Time
- 0 60
338...353 Max. frequency REAL +
PN Time
Hz 45 61
354...369 Max. apparent power L1L2L3 REAL +
PN Time
VA 0 67
370...385 Max. active power L1L2L3 REAL +
PN Time
W -3.0 x 10
9
65
386...401 Max. reactive power Qtot L1L2L3 REAL +
PN Time
var -3.0 x 10
9
61138
402...417 Max. power factor λ L1L2L3 REAL +
PN Time
- 0 68
418...433 Max. reactive power Qn L1 REAL +
PN Time
var -3.0 x 10
9
55
434...449 Max. reactive power Qn L2 REAL +
PN Time
var -3.0 x 10
9
56
450...465 Max. reactive power Qn L3 REAL +
PN Time
var -3.0 x 10
9
57
466...481 Max. mean voltage L-N REAL +
PN Time
V 0 62
482...497 Max. mean voltage L-L REAL +
PN Time
V 0 63
498...513 Max. sum mean value current L1L2L3 REAL +
PN Time
A 0 64
514...529 Max. fundamental voltage L1 REAL +
PN Time
V 0 62152
530...545 Max. fundamental voltage L2 REAL +
PN Time
V 0 62252
546...561 Max. fundamental voltage L3 REAL +
PN Time
V 0 62352
562...577 Max. fundamental current L1 REAL +
PN Time
A 0 62153
