Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
132 Manual, 07/2018, A5E42674880-AA
Technical specifications
15
15.1
Technical specifications
Technical specifications of the AI Energy Meter HF
The following table shows the technical specifications as of 07/2018. You will find a data
sheet including daily updated technical specifications on the Internet
(https://support.industry.siemens.com/cs/ww/en/pv/6ES7134-6PA00-0CU0/td?dl=en
).
Article number
6ES7134-6PA00-0CU0
General information
Product type designation AI Energy Meter 480 VAC/CT HF, PU 1
Firmware version V6.0
FW update possible
Yes
usable BaseUnits BU type U0
Color code for module-specific color identifica-
tion plate
CC20
Supported power supply systems
TT, TN, IT
Product function
Voltage measurement
Yes
without voltage transformer
Yes
with voltage transformer
Yes
Current measurement
Yes
without current transformer
No
with current transformer
Yes; 1 A or 5 A current transformer
with Rogowski coil
No
with current/voltage transformer
No
Energy measurement
Yes
Frequency measurement
Yes
Power measurement
Yes
Active power measurement
Yes
Reactive power measurement
Yes
Power factor measurement
Yes
Active factor measurement
Yes
Reactive power compensation
Yes
Line analysis
Yes
