Technical specifications
15.1 Technical specifications
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
133
– Monitoring of instantaneous and half-
wave values
Yes
– THD measurement for current and volt-
age
Yes
– Harmonics for current and voltage
Yes
– Voltage dip (DIP)
Yes
– Voltage swell
Yes
• I&M data
Yes; I&M0 to I&M3
• Isochronous mode
No
• STEP 7 TIA Portal configurable/integrated
as of version
STEP 7 V15 or higher
• STEP 7 configurable/integrated as of ver-
sion
Configurable via GSD file
• PROFIBUS as of GSD version/GSD revi-
sion
One GSD file each, Revision 3 and 5 and higher
• PROFINET as of GSD version/GSD revi-
sion
V2.3
• Switching between operating modes in
RUN
Yes; For module version 32 I/20 Q, it is possible
to dynamically switch between 25 user data vari-
ants, 23 of which are pre-defined and 2 of which
can be defined by the specific user
• Cyclic measured value access
Yes
• Acyclic measured value access
Yes
• Fixed measured value sets
Yes
• Freely definable measured value sets
Yes
CiR – Configuration in RUN
Reparameterization possible in RUN
Calibration possible in RUN
Installation type/mounting
Design of the power supply
permissible range, lower limit (DC)
permissible range, upper limit (DC)
Current consumption (rated value)
Current consumption, max.
