Siemens SIMATIC ET 200SP User Manual

Technical specifications
15.1 Technical specifications
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
134 Manual, 07/2018, A5E42674880-AA
Article number
6ES7134-6PA00-0CU0
Power loss
Power loss, typ.
1.4 W; 4x 5 A input current, 3x 230 V AC
Address area
Address space per module
• Inputs
256 byte
• Outputs
20 byte
Hardware configuration
Automatic encoding
Yes
• Mechanical coding element
Yes
Selection of BaseUnit for connection variants
• 2-wire connection
BU type U0
Time of day
Operating hours counter
• present
Yes
Analog inputs
Cycle time (all channels), typ. 50 ms; Time for consistent update of all meas-
ured and calculated values (cyclic und acyclic
data)
Cable length
• shielded, max.
200 m
• unshielded, max.
200 m
Analog value generation for the inputs
Sampling frequency, max.
2 048 kHz
Isochronous mode
Isochronous operation (application synchro-
nized up to terminal)
No
Interrupts/diagnostics/status information
Alarms
• Diagnostic alarm
Yes
• Limit value alarm
Yes
• Hardware interrupt
Yes; Monitoring of up to 16 freely selectable
process values (exceeding or undershooting of
value)

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
