Page #51 background imageLoading...
Page #51 background image
Reading and processing measured values
6.3 Reading measured values from user data cyclically
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
50 Manual, 07/2018, A5E42674880-AA
6.3
Reading measured values from user data cyclically
Requirement
STEP 7 is open.
The AI Energy Meter HF Is configured.
Scaling of measured values in the user data
Since the value range of 16-bit values is often smaller than the value range of the physical
value, a scaling factor is supplied together with the basic value in the user data for the
respective measured or calculated values. You determine the actual value of the measured
variable with the following formula:
Actual value of measured quantity = measured value in the user data x 10
scaling factor
Procedure
To read measured values from the user data cyclically, proceed as follows:
1. Read the relevant measured value from the input data.
2. Observe the scaling factor at scaled measured values and convert the read measured
value using the scaling factor.
Example
The user data variant 254 (FE
H
) "Total power L1L2L3" is configured on the AI Energy Meter
HF. The measured value for "Current L1" should be read.
Table 6- 1 Total power L1L2L3
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
254 (FE
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit
string
qq xx xx xx -
2 ... 3
Current L1
UINT
1 mA
0 … 65535
66007
4 ... 5 Current L2 UINT 1 mA 0 … 65535 66008
6 ... 7
Current L3
UINT
1 mA
0 … 65535
66009
8 ... 9
Total active power L1L2L3
INT
1 W
-27648 … 27648
66034
10 ... 11
Total reactive power Qtot L1L2L3
INT
1 var
-27648 … 27648
66038
12 ... 13
Total apparent power L1L2L3
INT
1 VA
-27648 … 27648
66036
14 ... 17 Total active energy L1L2L3 DINT 1 Wh -2147483647 to
+2147483647
225
