Siemens SIMATIC ET 200SP User Manual

Measured value data records
E.2 Measured value data record for base measurements (DS 142)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
229
Procedure
Data record 142 is located on the AI Energy Meter HF. Use the RDREC instruction to read
out the data record from the module. This system function block is stored in the STEP 7
library.
E.2.2
Measured value data record for basic measured values (DS 142) version 3
Measured variables of the module
The following table provides an overview of all the measured variables that data record 142
supplies. Please note that, depending on the connection type used the display of some
measured variables does not make sense and that the module deletes measured values that
are not relevant.
The measured value identification (measured value ID) is an index which references the
overview table of the measured variables in appendix (Measured variables (Page 163)).
Table E- 2 Data record 142
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
0
Version = 3
BYTE
-
-
-
1 Reserved BYTE - - -
2...5
Voltage L1-N
REAL
V
0.0 ... 1000000.0
1
6...9 Voltage L2-N REAL V 0.0 ... 1000000.0 2
10...13
Voltage L3-N
REAL
V
0.0 ... 1000000.0
3
14...17
Voltage L1-L2
REAL
V
0.0 ... 1000000.0
4
18...21
Voltage L2-L3
REAL
V
0.0 ... 1000000.0
5
22...25
Voltage L3-L1
REAL
V
0.0 ... 1000000.0
6
26...29
Current L1
REAL
A
0.0 … 100000.0
7
30...33
Current L2
REAL
A
0.0 … 100000.0
8
34...37
Current L3
REAL
A
0.0 … 100000.0
9
38...41
Power factor λ L1
REAL
-
0.0 ... 1.0
19
42...45
Power factor λ L2
REAL
-
0.0 ... 1.0
20
46...49
Power factor λ L3
REAL
-
0.0 ... 1.0
21
50...53
Total power factor L1L2L3
REAL
-
0.0 ... 1.0
37
54...57
Frequency
REAL
1 Hz
45.0 ... 65.0
30
58...61
Amplitude unbalance for voltage U
2
REAL
%
0 ... 100
61157
62...65
Amplitude unbalance for current I
unsym
REAL
%
0 to 100
61158
66...69
Apparent power L1
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
10
70...73
Apparent power L2
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
11
74...77
Apparent power L3
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
12
78...81
Total apparent power L1L2L3
REAL
VA
-3.0 x 10
9
… +3.0 x 10
9
36
