Siemens SIMATIC ET 200SP User Manual

Measured value data records
E.15 Measured value data record for harmonics current (DS 163)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
266 Manual, 07/2018, A5E42674880-AA
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
126...129
Harmonics 30: Current L1
REAL
A
0.0 ... 100000.0
63059
130...133 Harmonics 31: Current L1 REAL A 0.0 ... 100000.0 63061
134...137
Harmonics 32: Current L1
REAL
A
0.0 ... 100000.0
63063
138...141 Harmonics 33: Current L1 REAL A 0.0 ... 100000.0 63065
142...145
Harmonics 34: Current L1
REAL
A
0.0 ... 100000.0
63067
146...149
Harmonics 35: Current L1
REAL
A
0.0 ... 100000.0
63069
150...153
Harmonics 36: Current L1
REAL
A
0.0 ... 100000.0
63071
154...157
Harmonics 37: Current L1
REAL
A
0.0 ... 100000.0
63073
158...161
Harmonics 38: Current L1
REAL
A
0.0 ... 100000.0
63075
162...165
Harmonics 39: Current L1
REAL
A
0.0 ... 100000.0
63077
166...169
Harmonics 40: Current L1
REAL
A
0.0 ... 100000.0
63079
170...173
THD+N current L2
REAL
1%
0% to 100%
62221
174...177
Current L2
REAL
A
0.0 ... 100000.0
8
178...181
Harmonics 1: Current L2
REAL
A
0.0 ... 100000.0
63401
182...185
Harmonics 2: Current L2
REAL
A
0.0 ... 100000.0
63403
186...189
Harmonics 3: Current L2
REAL
A
0.0 ... 100000.0
63405
190...193
Harmonics 4: Current L2
REAL
A
0.0 ... 100000.0
63407
194...197
Harmonics 5: Current L2
REAL
A
0.0 ... 100000.0
63409
198...201
Harmonics 6: Current L2
REAL
A
0.0 ... 100000.0
63411
202...205
Harmonics 7: Current L2
REAL
A
0.0 ... 100000.0
63413
206...209 Harmonics 8: Current L2 REAL A 0.0 ... 100000.0 63415
210...213
Harmonics 9: Current L2
REAL
A
0.0 ... 100000.0
63417
214...217
Harmonics 10: Current L2
REAL
A
0.0 ... 100000.0
63419
218...221
Harmonics 11: Current L2
REAL
A
0.0 ... 100000.0
63421
222...225
Harmonics 12: Current L2
REAL
A
0.0 ... 100000.0
63423
226...229
Harmonics 13: Current L2
REAL
A
0.0 ... 100000.0
63425
230...233 Harmonics 14: Current L2 REAL A 0.0 ... 100000.0 63427
234...237
Harmonics 15: Current L2
REAL
A
0.0 ... 100000.0
63429
238...241
Harmonics 16: Current L2
REAL
A
0.0 ... 100000.0
63431
242...245
Harmonics 17: Current L2
REAL
A
0.0 ... 100000.0
63433
246...249
Harmonics 18: Current L2
REAL
A
0.0 ... 100000.0
63435
250...253
Harmonics 19: Current L2
REAL
A
0.0 ... 100000.0
63437
254...257
Harmonics 20: Current L2
REAL
A
0.0 ... 100000.0
63439
258...261
Harmonics 21: Current L2
REAL
A
0.0 ... 100000.0
63441
262...265
Harmonics 22: Current L2
REAL
A
0.0 ... 100000.0
63443
266...269
Harmonics 23: Current L2
REAL
A
0.0 ... 100000.0
63445
270...273
Harmonics 24: Current L2
REAL
A
0.0 ... 100000.0
63447
274...277
Harmonics 25: Current L2
REAL
A
0.0 ... 100000.0
63449
278...281
Harmonics 26: Current L2
REAL
A
0.0 ... 100000.0
63451
281...285
Harmonics 27: Current L2
REAL
A
0.0 ... 100000.0
63453
