Siemens SIMATIC ET 200SP User Manual

Interrupts/diagnostic alarms
14.4 Diagnostics response
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
122 Manual, 07/2018, A5E42674880-AA
Parameter assignment
The following table shows the necessary parameters:
Table 14- 12 Parameter assignment
Parameter
Power quality analysis function (module)
Enable
Determine peak value voltage (channel) Enable
Example
The following figure is a schematic diagram of the principle of operation:
①
Voltage peak in L1
②
Status "Power quality voltage peak"
③
Bit "Reset status "power quality""
④
Max. voltage peaks instantaneous value can be read out
Figure 14-6 Example of principle of operation
