Parameter data records
A.3 Structure of the parameter data record 129 for limit monitoring
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
156 Manual, 07/2018, A5E42674880-AA
The following table shows the module-specific error codes and their meaning for the
parameter data record 129.
Error code in STATUS parameter
(hexadecimal)
Meaning
Solution
Byte 0
Byte 1
Byte 2
Byte 3
DF
80
B0
00
Number of the data record unknown
Enter a valid number for the data record.
DF 80 B1 01 Length of the data record incorrect Enter a valid value for the data record
length.
DF 80 B2 00 Slot invalid or cannot be accessed. Check the station whether the module is
plugged or drawn.
Check the assigned values for the pa-
rameters of the WRREC instruction
DF
80
E0
01
Incorrect version
Check Byte 0. Enter valid values.
DF 80 E0 02 Error in the header information Check Bytes 1 and 2. Correct the length
and number of the parameter blocks.
DF 80 E1 01 Reserved bits are not 0. Check bytes 3, 13, 23, 33...163 and set
the reserved bits back to 0.
DF
80
E1
31
"Length of the parameter block" invalid.
Check Byte 1. Length = 10 bytes
DF
80
E1
32
"Number of parameter blocks" invalid.
Check Byte 2. Enter valid values.
DF 80 E1 33 "ID of the measured value for limit moni-
toring" invalid.
Check Bytes 4 and 5. Enter valid values.
DF 80 E1 34 Parameters for monitoring the limits
invalid
Check bits 0...3 in Byte 6. Enter valid
values.
DF 80 E1 35 "Number of limit" in 'Monitoring assigned
multiple times' parameter
Check bits 0...3 in Byte 6. Do not use
limit number several times.
DF
80
E1
36
"Hysteresis for limit monitoring" invalid
Check Byte 7. Enter valid values.
DF
80
E1
37
"Limit" invalid.
Check Byte 8...11. Enter valid values.
DF 80 E1 38 "Delay time for limit monitoring" invalid. Check Byte 12. Enter valid values.
