Siemens SIMATIC ET 200SP User Manual

Product overview
2.1 Properties of the AI Energy Meter HF
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
15
Properties
The module has the following technical properties:
● Measurement of electrical variables from single-phase, two-phase and three-phase
supply networks
● Max. nominal voltage between two line conductors 480 V AC
● Retentive storage of the counter values
● Use on frequency converters
● Recording of:
– Voltages
– Currents
– Phase angles
– Power
– Energy / electrical work
– Frequencies
– Minimum and maximum values with time stamp
– Power factors
– Operating hours
– Limits
– Power quality data for voltages and currents
The module supports the following functions:
Table 2- 1 Version dependencies of the functions
Function
HW
ver-
sion
FW version
STEP 7
GSD file
TIA Portal
PROFINET IO
PROFIBUS DP
Firmware update
FS01
V6.0.0 or higher
V15 or higher with HSP0253
X
---
Calibration in runtime
FS01
V6.0.0 or higher
V15 or higher with HSP0253
---
---
Identification data I&M0 to
I&M3
FS01 V6.0.0 or higher V15 or higher with HSP0253 X X
Reconfiguration in RUN
FS01
V6.0.0 or higher
V15 or higher with HSP0253
X
X
Diagnostic interrupts
FS01
V6.0.0 or higher
V15 or higher with HSP0253
X
X
Hardware interrupts
FS01
V6.0.0 or higher
V15 or higher with HSP0253
X
---
Note
The AI Energy
Meter HF is released as of TIA Portal V15.0.0.2.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
