Siemens SIMATIC ET 200SP User Manual

User data variants
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
224 Manual, 07/2018, A5E42674880-AA
Basic variables phase-specific measurement (ID 155 or 9B
H
)
Table D- 23 Basic variables phase-specific measurement L3
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
155 (9B
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit string qq xx xx xx -
2 ... 3
Current L3
UINT
1 mA
0 … 65535
66009
4 ... 5
Voltage UL3-N
UINT
0.01 V
0 … 65535
66003
6 ... 7
Active power L3
INT
1 W
-27648 … 27648
66015
8 ... 9
Reactive power Qtot L3
INT
1 var
-27648 … 27648
66024
10 ... 11
Apparent power L3
INT
1 VA
-27648 … 27648
66012
12 ... 15 Active energy L3 total (inflow - outflow) DINT 1 Wh -2147483647...
+2147483647
62315
16 ... 19 Reactive energy L3 total (inflow - outflow) DINT 1 varh -2147483647...
+2147483647
62316
20 ... 23
Apparent energy L3
UDINT
1 VAh
0 to 2147483647
62314
24
Scaling current L3
USINT
-
0 ... 255
-
25
Scaling active power L3
USINT
-
0 ... 255
-
26
Scaling reactive power L3
USINT
-
0 ... 255
-
27
Scaling apparent power L3
USINT
-
0 ... 255
-
28
Scaling active energy L3 total (inflow - outflow)
USINT
-
0 ... 255
-
29
Scaling reactive energy L3 total (inflow - outflow)
USINT
-
0 ... 255
-
30
Scaling apparent energy L3
USINT
-
0 ... 255
-
31
Power factor L3
USINT
0.01
0 … 100
66021
