Siemens SIMATIC ET 200SP User Manual

Measured value data records
E.7 Measured value data record for minimum values with time stamp (DS 155)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
247
Byte
Measured variable
Data
type
Unit
Default
Meas-
ured
value
ID
578...593 Min. fundamental current L2 REAL +
PN Time
A 1000000 62273
594...609 Min. fundamental current L3 REAL +
PN Time
A 1000000 62373
610...625 Min. fundamental apparent power L1 REAL +
PN Time
VA +3.0 x 10
9
62175
626...641 Min. fundamental apparent power L2 REAL +
PN Time
VA +3.0 x 10
9
62275
642...657 Min. fundamental apparent power L3 REAL +
PN Time
VA +3.0 x 10
9
62375
658...673 Min. fundamental reactive power L1 REAL +
PN Time
var +3.0 x 10
9
62174
674...689 Min. fundamental reactive power L2 REAL +
PN Time
var +3.0 x 10
9
62274
690...705 Min. fundamental reactive power L3 REAL +
PN Time
var +3.0 x 10
9
62374
706...721 Min. fundamental active power L1 REAL +
PN Time
W +3.0 x 10
9
62176
722...737 Min. fundamental active power L2 REAL +
PN Time
W +3.0 x 10
9
62276
738...753 Min. fundamental active power L3 REAL +
PN Time
W +3.0 x 10
9
62376
754...769 Min. fundamental cos φ active factor L1 REAL +
PN Time
- 1 62177
770...785 Min. fundamental cos φ active factor L2 REAL +
PN Time
- 1 62277
786...801 Min. fundamental cos φ active factor L3 REAL +
PN Time
- 1 62377
802...817 Min. THD+N voltage L1 REAL +
PN Time
1% 100 62170
818...833 Min. THD+N voltage L2 REAL +
PN Time
1% 100 62270
834...849 Min. THD+N voltage L3 REAL +
PN Time
1% 100 62370
850...865 Min. THD+N current L1 REAL +
PN Time
1% 100 62171
866...881 Min. THD+N current L2 REAL +
PN Time
1% 100 62271
882...897 Min. THD+N current L3 REAL +
PN Time
1% 100 62371
1
The values reference the amount of the current measured value
