Measured value data records
E.14 Measured value data record for harmonics voltage (DS 161)
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
263
Byte
Measured variable
Data
type
Unit
Value range
Meas-
ured
value
ID
286...289
Harmonics 28: Voltage L2
REAL
V
0.0 ... 760.0
63454
290...293 Harmonics 29: Voltage L2 REAL V 0.0 ... 760.0 63456
294...297
Harmonics 30: Voltage L2
REAL
V
0.0 ... 760.0
63458
298...301 Harmonics 31: Voltage L2 REAL V 0.0 ... 760.0 63460
302...305
Harmonics 32: Voltage L2
REAL
V
0.0 ... 760.0
63462
306...309
Harmonics 33: Voltage L2
REAL
V
0.0 ... 760.0
63464
310...313
Harmonics 34: Voltage L2
REAL
V
0.0 ... 760.0
63466
314...317
Harmonics 35: Voltage L2
REAL
V
0.0 ... 760.0
63468
318...321
Harmonics 36: Voltage L2
REAL
V
0.0 ... 760.0
63470
322...325
Harmonics 37: Voltage L2
REAL
V
0.0 ... 760.0
63472
326...329
Harmonics 38: Voltage L2
REAL
V
0.0 ... 760.0
63474
330...333
Harmonics 39: Voltage L2
REAL
V
0.0 ... 760.0
63476
334...337
Harmonics 40: Voltage L2
REAL
V
0.0 ... 760.0
63478
338...341
THD+N voltage L3
REAL
1%
0% to 100%
62320
342...345
Voltage L3
REAL
V
0.0 ... 440.0
3
346...349
Harmonics 1: Voltage L3
REAL
V
0.0 ... 760.0
63800
350...353
Harmonics 2: Voltage L3
REAL
V
0.0 ... 760.0
63802
354...357
Harmonics 3: Voltage L3
REAL
V
0.0 ... 760.0
63804
358...361
Harmonics 4: Voltage L3
REAL
V
0.0 ... 760.0
63806
362...365
Harmonics 5: Voltage L3
REAL
V
0.0 ... 760.0
63808
366...369 Harmonics 6: Voltage L3 REAL V 0.0 ... 760.0 63810
370...373
Harmonics 7: Voltage L3
REAL
V
0.0 ... 760.0
63812
374...377
Harmonics 8: Voltage L3
REAL
V
0.0 ... 760.0
63814
378...381
Harmonics 9: Voltage L3
REAL
V
0.0 ... 760.0
63816
382...385
Harmonics 10: Voltage L3
REAL
V
0.0 ... 760.0
63818
386...389
Harmonics 11: Voltage L3
REAL
V
0.0 ... 760.0
63820
390...393 Harmonics 12: Voltage L3 REAL V 0.0 ... 760.0 63822
394...397
Harmonics 13: Voltage L3
REAL
V
0.0 ... 760.0
63824
398...401
Harmonics 14: Voltage L3
REAL
V
0.0 ... 760.0
63826
402...405
Harmonics 15: Voltage L3
REAL
V
0.0 ... 760.0
63828
406...409
Harmonics 16: Voltage L3
REAL
V
0.0 ... 760.0
63830
410...413
Harmonics 17: Voltage L3
REAL
V
0.0 ... 760.0
63832
414...417
Harmonics 18: Voltage L3
REAL
V
0.0 ... 760.0
63834
418...421
Harmonics 19: Voltage L3
REAL
V
0.0 ... 760.0
63836
422...425
Harmonics 20: Voltage L3
REAL
V
0.0 ... 760.0
63838
426...429
Harmonics 21: Voltage L3
REAL
V
0.0 ... 760.0
63840
430...433
Harmonics 22: Voltage L3
REAL
V
0.0 ... 760.0
63842
434...437
Harmonics 23: Voltage L3
REAL
V
0.0 ... 760.0
63844
438...441
Harmonics 24: Voltage L3
REAL
V
0.0 ... 760.0
63846
442...445
Harmonics 25: Voltage L3
REAL
V
0.0 ... 760.0
63848
