Service and maintenance
11.9 Reinstalling the software
SIMATIC HMI IPC677C
Operating Instructions, 04/2013, A5E02722710-04
151
Procedure
1. If necessary, connect a DVD drive to the USB interface.
2. Insert the Recovery DVD into the DVD drive.
3. Reboot the device.
4. Press the <F12> key when the following BIOS message appears.
Press F2 to go to Setup Ulility
Press F12 to go to Boot Manager
After initialization, a boot menu is displayed.
5. In the boot menu, select the optical drive using the cursor keys. It is identified by a "P" in
front of the SATA port number.
Example:
P3 - OPTIARC DVD-ROM DDU1681S
6. Confirm the selection by pressing ENTER.
7. Immediately press any key when you see the following prompt to install the operating
system from the Recovery DVD.
Press any key to boot from CD ..
The Windows XP installation program (blue screen) appears after a few seconds.
8. Follow the instructions of the Windows XP installation program. You can find additional
information on this in the section: Windows XP installation program
Windows XP installation program
The language of the installation program and the Windows XP Professional operating
system is preset to English. You can change the language of Windows XP Professional once
you have installed it. You can find information on this in section: Auto-Hotspot.
Partitions in the delivery state for Windows XP
The recommended minimum size of the partition on which you want to install Windows XP
varies depending on how much work memory and which additional software you want to use.
Information on partitioning of the data carrier in the delivery state is provided in the following
table.
Partition Name Size File system
First SYSTEM 25 GB NTFS not compressed
Second DATA Remainder NTFS not compressed
