Siemens SIMATIC HMI IPC677C - 2 Description; Design of IPC677 C

SIMATIC HMI IPC677C
Operating Instructions, 04/2013, A5E02722710-04
19
Description
2
2.1 Design of IPC677C
Design
 
(1) Computer unit
(2) Control unit
Figure 2-1 IPC677C
Product Brief
The device is available with different control units which are distinguished by the size of the
display and by the key or touch panel.
