Description
2.2 Features
SIMATIC HMI IPC677C
Operating Instructions, 04/2013, A5E02722710-04
21
2.2 Features
Basic data
Design Panel mounting device, box
Processor
• Intel® Celeron™ P4505 mobile processor 1.86 GHz,
2 MB second-level cache, 2 cores / 2 threads,
virtualization
• Intel® Core™ i3-330E mobile processor 2.13 GHz,
3 MB second-level cache, 2 cores /4 threads,
hyperthreading, virtualization
• Intel® Core™ i7-610E mobile processor 2.53 GHz,
4 MB second-level cache, 2 cores / 4 threads, hyper-
threading, turbo boost, virtualization, AMT
Chipset
• Mobile Intel® QM57 Express Chipset
Main memory
• 1 GB SDRAM (DDR3)
• Expandable to up to 8 GB SDRAM (DDR3)
• ECC, optional
Slots for expansions
• 1x PCI 290 mm long and 1x PCI 185 mm long
• 1x PCI 290 mm long and 1x PCI Express x16 185 mm
long
Graphics
• Intel® HD graphics controller,
chip set integrated 2-D and 3-D engine,
Dynamic Video Memory Technology
(uses up to 256 MB RAM)
• CRT:
Max. 1280x1024 at 100 Hz / 32-bit color depth
Max. 1600x1200 at 60 Hz / 32-bit color depth
Maximum resolution:
2038x1536 at 75 Hz / 16-bit color depth
• LCD via DVI-I: 1600x1200 at 60 Hz / 32-bit color depth
Power supply
• 100 - 240 VAC, 190 W; wide range
• 24 V DC, 210 W
Both with bridging of transient loss of voltage according to
NAMUR: max. 20 ms.
The 24V DC power supply is protected against reversed
polarity.
Drives and storage media
Mass storage
• 1 x 3.5" hard disk or
• 2 x 2.5" hard disk or RAID1 system
Capacity see order forms
DVD drive DVD burner
Flash memory
• Slot for Compact Flash card
• 1 x solid-state drive
