Siemens SIMATIC HMI IPC677C User Manual

Technical data
14.1 General specifications
SIMATIC HMI IPC677C
176 Operating Instructions, 04/2013, A5E02722710-04
Disk drives
Hard disks 2.5'' or 3.5'' Serial ATA, hard disk capacity see order documentation
• 3 Gbps data transfer rate
• Supports NCQ (Native Command Queuing) SATA II property
DVD burner Serial ATA, See order documentation for features
Oscillations, max.: 10 to 58 Hz: 0.019 mm / 58 to 500 Hz: 2.5 m/s2
Burner operation only permissible in interference-free environment
Display
Graphics controller Intel® HD Graphics Controller,
2-D and 3-D engine integrated in chipset
Graphics memory Dynamic Video Memory Technology
(uses up to 256 MB of RAM)
Resolutions, frequencies, color depth CRT:
Max. 1280x1024 at 100 Hz/32-bit color depth
Max. 1600x1200 at 60 Hz/32-bit color depth
Maximum resolution:
2038x1536 at 75 Hz/16-bit color depth
LCD via DVI-I: 1600x1200 at 60 Hz / 32-bit color depth
Color display*
)
12" TFT
Key panel
15" TFT
Key panel
12" TFT
Touch panel
15" TFT (INOX)
Touch panel
19" TFT
Touch panel
Resolution 800 x 600 1024 x 768 800 x 600 1024 x 768 1280 x 1024
Contrast ratio, typ. 600:1 450:1 450:1 450:1 700:1
Max. light density cd/m²,
typ.
350 250 350 250 300
Horizontal viewing angle
right/left/typ./min.
70° / 60° 60° / 50° 70° / 60° 60° / 50° typically 80°
Vertical viewing angle l
above / typ. / min.
45° / 35° 40° / 30° 45° / 35° 40° / 30° typically 80°
Vertical viewing angle l
below / typ. / min.
55° / 45° 60° / 35° 55° / 45° 60° / 35° typically 80°
*
)
A small number of faults in the display is unavoidable. However, the displays do comply with the described quality
standards of the ISO standard 13406-2, class 2.
*
)
Bad pixels
• Permanently bright, dark pixels
• Permanently bright, green pixels
Permissible number
• ≤ 12
• ≤ 5
