Detailed descriptions
16.2 Bus board
SIMATIC HMI IPC677C
214 Operating Instructions, 04/2013, A5E02722710-04
Signal Pin no. Pin no. Signal
PCIEX16_TX_P(9) B41 A41 GND
PCIEX16_TX_N(9) B42 A42 GND
GND B43 A43 PCIEX16_RX_P(9)
GND B44 A44 PCIEX16_RX_N(9)
PCIEX16_TX_P(8) B45 A45 GND
PCIEX16_TX_N(8) B46 A46 GND
GND B47 A47 PCIEX16_RX_P(8)
MCH_CFG_20 B48 A48 PCIEX16_RX_N(8)
GND B49 A49 GND
PCIEX16_TX_P(7) B50 A50 n.c.
PCIEX16_TX_N(7) B51 A51 GND
GND B52 A52 PCIEX16_RX_P(7)
GND B53 A53 PCIEX16_RX_N(7)
PCIEX16_TX_P(6) B54 A54 GND
PCIEX16_TX_N(6) B55 A55 GND
GND B56 A56 PCIEX16_RX_P(6)
GND B57 A57 PCIEX16_RX_N(6)
PCIEX16_TX_P(5) B58 A58 GND
PCIEX16_TX_N(5) B59 A59 GND
GND B60 A60 PCIEX16_RX_P(5)
GND B61 A61 PCIEX16_RX_N(5)
PCIEX16_TX_P(4) B62 A62 GND
PCIEX16_TX_N(4) B63 A63 GND
GND B64 A64 PCIEX16_RX_P(4)
GND B65 A65 PCIEX16_RX_N(4)
PCIEX16_TX_P(3) B66 A66 GND
PCIEX16_TX_N(3) B67 A67 GND
GND B68 A68 PCIEX16_RX_P(3)
GND B69 A69 PCIEX16_RX_N(3)
PCIEX16_TX_P(2) B70 A70 GND
PCIEX16_TX_N(2) B71 A71 GND
GND B72 A72 PCIEX16_RX_P(2)
GND B73 A73 PCIEX16_RX_N(2)
PCIEX16_TX_P(1) B74 A74 GND
PCIEX16_TX_N(1) B75 A75 GND
GND B76 A76 PCIEX16_RX_P(1)
GND B77 A77 PCIEX16_RX_N(1)
PCIEX16_TX_P(0) B78 A78 GND
PCIEX16_TX_N(0) B79 A79 GND
GND B80 A80 PCIEX16_RX_P(0)
n.c. B81 A81 PCIEX16_RX_N(0)
n.c. B82 A82 GND
